PLC Control Panel for Industrial Automation Equipment
Details
Product Features
● High Adaptability
Supports DIN rail mounting and modular PLC layout, compatible with PLCs of major brands such as Siemens, Mitsubishi, and ABB.
Offers standardized or customized PLC enclosure dimensions to adapt to the diverse requirements of micro PLCs to large-scale control systems.
● Convenient Installation
Features detachable panels, pre-installed rails, and modular partitions, simplifying the assembly process and reducing installation time.
● Strong Expansion Capability
Designed with reserved redundant space, cable entry holes, terminal block mounting positions, modular expansion slots, and other details in the internal layout to facilitate future system expansion.
 |
 |
 |
Product Parameters
| Parameters | Specification |
| Product Model | INNO-PLC-0519 |
| Brand/Manufacturer | Yinlu |
| Applicable PLC Types | Supports small PLCs (e.g., S7-200 SMART), medium PLCs (e.g., Q series), and modular PLCs (e.g., ControlLogix) |
| Enclosure Material | Cold-rolled steel |
| Enclosure Dimensions | 800×600×2000 mm |
| Installation Dimensions | Supports DIN rail (35mm standard spacing), compatible with TS35/7.5 or TS35/15 rails |
| Material Thickness | 1.5mm |
| Color | RAL7035 |
| Protection Level | IP65 |
| Operating Temperature Range | -20℃~+60℃ (without cooling); -40℃~+80℃ (with cooling/heating module, optional) |
| Humidity Range | ≤95% RH (non-condensing) |
| Installation Method | Floor Standing |
| Internal Layout | Reserved areas for PLC installation, terminal block space, and cable trays (supports cable diameter ≤20mm) |
| Cooling Design | Top cooling vents (with dust filters), temperature-controlled fan (automatically starts when temperature ≥50℃, optional) |
| Modular Design | Expandable side panels (for adding I/O module installation slots), detachable bottom plate (for easy cable management) |
| Compliance Standards | IEC 62208 |
Product Details
|
Door Lock The PLC enclosure is equipped with a high-strength anti-theft door lock to prevent unauthorized personnel from unlawfully accessing it, thus safeguarding the safety of internal equipment.
|
File Box The door of the PLC enclosure features an integrated built-in document holder, which can store supporting drawings and specifications related to the product.
|
Foaming The door adopts a circumferential sealing design combined with high-quality EPDM sealing strips, ensuring compliance with IP ratings, isolating external contaminants, and providing a comfortable operating environment for the electrical components inside the PLC enclosure. |
|
Grounding Wire Pre-installed grounding terminals are provided at the bottom of the PLC enclosure to ensure reliable grounding and prevent electric leakage.
|
Hanging Ring Thickened and reinforced lifting rings are installed at the top to guarantee structural stability during installation and transportation, avoiding unintended detachment. |
Powerful Hinges High-strength hinges made of 304 stainless steel are used, ensuring smooth operation without jamming or noise even with frequent opening and closing.
|
Production Process
1. Prototype Design
2. Laser Cutting
3. Bending
4. Welding
5. Polishing
6. Powder Coating
7. Assembly
8. Quality Control
9. Package
Production Process
1. Prototype Design
2. Laser Cutting
3. Bending
4. Welding
5. Polishing
6. Powder Coating
7. Assembly
8. Quality Control
9. Package
Reviews
FAQ
Our services cover full-range manufacturing processes for sheet metal products, including laser cutting, bending, welding, surface treatment, assembly, and testing.
We process mainstream metal sheets such as galvanized steel, cold-rolled steel, stainless steel, and aluminum alloy, accommodating customized thickness requirements from 0.5mm to 10mm.
We offer processes like powder coating, painting, electroplating, anodizing, brushing, and sandblasting. Leveraging our expertise, we recommend suitable surface treatments based on the specific application environment.
Yes, Yinlu supports non-standard customization and production based on provided drawings. Our engineers will optimize the structure during secondary design to deliver more cost-effective solutions.
Our products are used in multiple sectors, including automation equipment, new energy, medical, and telecommunications. Key products include PLC control panels, electrical cabinets, charging pile enclosures, and medical equipment enclosures.
Absolutely. We offer one-stop ancillary services such as silkscreen printing (logos/identifications), assembly (including electrical components), and packaging (customized cartons/wooden crates).
